LPG/CNG Diaphragms
Premium LPG/CNG Diaphragms Engineered for Automotive Gas Regulation
Diaphragm thickness: 0.20mm to 0.50mm precision gauge
Temperature range: -40°C to +120°C all-weather performance
Pressure rating: Up to 15 kg/cm² stable operation
What Are LPG/CNG Diaphragms?
Automotive OEM Applications
Aftermarket Gas Conversion Kits
Gas Pressure Regulators
Our LPG/CNG Diaphragm Products
Auto-Rickshaw LPG/CNG Kit Diaphragms
Fabric-Reinforced Gas Regulator Diaphragms
Ultra-thin 0.20mm diaphragms with fabric reinforcement for LPG/CNG applications, highly sensitive to 0.1 kg/cm² pressure variations & resistant to extreme temperatures.
Single-Stage Regulator Diaphragms
Two-Stage Regulator Diaphragms
Commercial Vehicle CNG Diaphragms
Aftermarket Replacement Diaphragms
Sequential Injection System Diaphragms
Custom OEM Diaphragms
Types of LPG/CNG Diaphragms
Flat Fabric-Reinforced Diaphragms
Molded Fabric-Reinforced Diaphragms
Rolling Diaphragms
Designed to roll within regulator housing, minimizing wear. Used in high-displacement gas regulators and advanced pressure control systems. Offers extended service life in commercial applications.
Convoluted Diaphragms
Feature flexible folds for greater movement capability. Suitable for variable pressure applications and high-stroke regulator designs requiring compact size.
Dual-Layer Composite Diaphragms
Pressure-Sensing Diaphragms
Why Choose Ds Techno Rubber LPG/CNG Diaphragms?
High-Pressure Resistance
Zero-Failure Track Record
100% Leak Testing
Ultra-Precision Engineering
OEM-Trusted Quality
Custom Engineering Solutions
Gas-Resistant Materials
Automotive Standards Compliance
Features Of Our LPG/CNG Diaphragms
High Sensitivity and Precision
LPG/CNG Chemical Resistance
Extreme Durability
Superior Pressure Fidelity
Fabric-Reinforced Strength
Zero-Leak Integrity
Custom LPG/CNG Diaphragms for Your Needs
Get in touch today to discuss custom LPG/CNG Diaphragms tailored to your precise needs!
Industries We Serve
Why DS Techno Rubber?
35+ Years of Expertise
We bring decades of experience in designing and manufacturing custom rubber components.
Precision Engineering
Each diaphragm is crafted with the highest level of attention to detail.
Superior Materials
We use only the finest rubber compounds to ensure durability and performance.
Global Reach
Serving industries in India, the USA, and Germany with high-quality products and on-time delivery.
FAQ
LPG/CNG diaphragms are specifically engineered with gas-resistant elastomers that resist swelling and degradation from hydrocarbon exposure. They feature ultra-thin construction (0.20mm) with fabric reinforcement for high sensitivity while maintaining durability—properties standard diaphragms lack.
Fabric reinforcement provides tensile strength and dimensional stability essential for millions of actuation cycles. It prevents tearing and permanent deformation while allowing thin rubber to remain flexible enough to respond to pressure changes as low as 0.1 kg/cm². Without reinforcement, thin diaphragms would fail prematurely.
These diaphragms are made from gas-resistant elastomers like Nitrile (NBR), Hydrogenated Nitrile (HNBR), and Epichlorohydrin (ECO), combined with reinforcement fabrics such as Nylon or Polyester. The choice depends on factors like LPG/CNG compatibility, temperature resistance (-40°C to +120°C), and required cycle life.
We manufacture diaphragms compatible with most major brands including Lovato, BRC, Tomasetto, Landi Renzo, and OEM regulators (Bajaj, Piaggio, TVS). For specific compatibility, provide regulator model or sample. We can also develop custom diaphragms for unique specifications.
Every diaphragm undergoes 100% individual leak testing using helium or pressure decay methods, plus visual and dimensional inspection. Batch samples undergo pressure cycling (5 million cycles), chemical resistance testing in LPG/CNG, temperature cycling, and tensile strength verification.
Yes, our LPG/CNG diaphragms comply with AIS-026 (Indian automotive LPG/CNG standards) and are ECE R110 compatible. We maintain comprehensive quality documentation and material certifications required by OEMs and regulatory bodies.
Standard designs: 100 pieces minimum. Custom designs requiring new tooling: 1,000-5,000 pieces depending on complexity. Prototype quantities (25-50 pieces) available for testing and validation at reasonable pricing.
We offer OEM-quality with zero-failure track record, 100% leak testing, local manufacturing (no import delays/duties), competitive pricing, technical support, and proven reliability with 3+ million units in service. Total cost of ownership is significantly lower than imports.
